AC100-240V 50/60HZ Outdoor LED Display P6 P10 P16 Video PBC RGB 256128mm 320mm320mm

Place of Origin : Guangdong, China

Model Number : Grock

Brand Name : GCL

Packaging Details : Packing with Flight case & Wooden box & Hard paper box

Supply Ability : 5000 Square Meter/Square Meters per Month

Price : Price to be discussed

MOQ : Min. order: 20

Certification : EMC/CE/ROHS/CCC/FCC/BIS

Application : Outdoor

Color : Full color

Panel Size : 256*128mm

LED chip : Nationstar

Cabinet size : 960x960mm

Brightness : 6500nits

Scan mode : 1/4scan

Usage : Advertising

Refresh rate : 1920Hz-3840Hz

Viewing angle : H120 V120

Cabinet material : Iron

Certificate : CE ROHS FCC

Input Voltage : AC100~240V 50 /60 HZ

Pixel Pitch : P8

Port : Shenzhen

Contact Now

Products Description

AC100-240V 50/60HZ Outdoor LED Display P6 P10 P16 Video PBC RGB 256*128mm 320mm*320mm

Product Parameter

Product	P6	P8	P10
Pitch(mm)	6	8	10
Density(pixels/m2)	27777	15625	10000
LED Type	SMD3535
Brightness(nits)	6500	6000	5500
Scan Method	1/8	1/4	1/3
Cabinet Material	Customized
Cabinet Weight	45kg/㎡
Protection Level	IP65
Cabinet Maintenance	100% Rear Service
Max Power Consumption	800w/㎡	800w/㎡	800w/㎡
Average Power Consumption	270w/㎡	270w/㎡	270w/㎡
Refresh Rate	2880-3840HZ
Grey Scale	16 bit
Viewing Angle	H160°,V140°
Voltage	AC100~240V(50-63Hz)
Working Temperature	-30 ℃- + 65 ℃
Working Humidity	10% -- 90%RH
Color Temperature	6500-9500K
Certificationa	EMC/CE/ROHS/CCC/FCC/ISO
